28 Ton Diesel Forklift for Long and Dense Industrial Loads
The Xinghao 28 Ton Diesel Forklift is published in the 28,000 kg heavy-lift class with a 1,220 mm standard load-center reference and a 4,000 mm standard lift configuration. Current product information also lists multiple diesel powertrain, transmission and heavy-load attachment options for project-specific builds.
28 Tons at 1,220 mm Is a Specific Load Condition
A heavy forklift should not be selected from gross cargo weight alone. Long steel products, stone blocks, coils and industrial machinery can place their center of gravity significantly farther from the fork face.
Check the Real Load Moment
If the actual center of gravity moves beyond the published reference, or an attachment adds forward thickness, usable capacity must be checked for that exact truck and load configuration.
Long Loads Need More Than a Higher Tonnage Number
The 1,220 mm published load-center reference makes this page particularly relevant to buyers handling deeper industrial loads, but every cargo type still needs its own support geometry reviewed.
Steel coils, stone blocks, machinery and fabricated structures can all place the center of gravity differently even at the same gross weight.
- Maximum routine cargo weight
- Length in the fork direction
- Actual center of gravity
- Fork-entry direction
- Support-point spacing
- Required lifting height
- Attachment mass and thickness
Send the Cargo Drawing
For coils, machinery, stone, dies or fabricated structures, mark the weight, overall dimensions, C.G. and permitted lifting points.
This is a better basis for selecting a 28 ton heavy forklift than using capacity class alone.
Powertrain, Mast and Braking Options
The current page publishes several component brands and configuration directions. They should be treated as options to be reconciled into one exact ordered build rather than combined automatically.
Do Not Combine Every Optional Feature into One Assumed Standard Truck
Engine brand, emission package, transmission, mast, cab equipment, tires and attachments all belong to specific builds. Procurement should freeze one complete configuration before price, documentation and spare parts are finalized.
Match the Load Interface to the Cargo Type
The current product page references several heavy-load attachment directions. Final suitability depends on the actual cargo, hydraulic requirement and resulting load center.
Where a 28 Ton Heavy Forklift Fits
Steel & Coil Handling
Evaluate coils, fabricated structures and dense steel loads using their actual center of gravity and required attachment.
Stone & Precast
Handle compatible blocks or precast cargo after load support, attachment and site surface conditions are verified.
Heavy Machinery
Move machinery and industrial assemblies where weight, C.G., lifting points and route dimensions are known.
25 Ton, 28 Ton or 30 Ton?
The correct class should follow the real load moment and worksite rather than adding nominal capacity simply for reassurance.
Compare FD250 when the actual load fits its published 25,000 kg / 1,220 mm reference and site envelope.
Compare 25 Ton →Use this page when the project requires the 28,000 kg class and the final configured truck supports the actual load geometry.
Compare the 30 ton platform when the load moment or required capacity exceeds the approved 28 ton build.
Compare 30 Ton →Heavy-Lift Selection Includes the Ground and Route
A high-capacity truck and its cargo place substantial demands on the operating route. Verify the complete loaded path before final machine approval.
Send These Details before Finalizing the 28 Ton Truck
Cargo
Maximum weight, dimensions and actual center of gravity.
Load Interface
Fork entry, support points, attachment and required insertion depth.
Worksite
Surface, turning area, gates, ramps and complete operating route.
Configuration
Mast, engine, transmission, emission requirement, quantity and destination.
Continue the Heavy-Lift Selection
28 Ton Diesel Forklift Buying Questions
The current product page publishes a 28,000 kg rated capacity class with a 1,220 mm standard load-center reference. Actual capacity should be confirmed for the final load, mast and attachment configuration.
No universal capacity should be assumed. The page publishes the rating around a 1,220 mm reference. Loads with a farther-forward center of gravity or added attachment thickness must be checked separately.
The current product page lists a 4,000 mm standard two-stage mast reference. Confirm the required fork height, lowered mast clearance and usable capacity at the working height.
The current page references Cummins, Volvo and Weichai diesel engine choices and ZF or Dana powershift transmission configurations. The exact pairing should be stated on the final quotation.
The current product page references coil rams, block clamps and fork positioners as attachment directions. Final suitability depends on the actual load weight, dimensions, C.G., attachment and working height.
Send maximum cargo weight and dimensions, center of gravity, fork-entry or attachment requirement, required lift height, worksite route, surface and slopes, powertrain preference, destination, emission requirement and quantity.
Configure the 28 Ton Forklift around the Real Load
Send the maximum cargo weight, dimensions, center of gravity, fork-entry geometry or attachment requirement, required lift height, worksite surface, turning areas and slopes, preferred engine or transmission, destination-market requirement and quantity. These inputs allow the 28 ton configuration to be checked against the actual handling task before quotation.
