1.5t - 3.5t Compact Electric
1.5–3.5 Ton Electric Forklifts for Warehouse and Factory Handling
Our 1.5–3.5 ton compact electric forklift range covers FB15, FB20, FB25, FB30 and FB35 capacity classes for pallet movement, production logistics, receiving and dispatch. Select the model from actual load weight, 500 mm rated load center, aisle and turning space, lift height and battery duty cycle.
Compare FB15 to FB35 by Actual Working Load
Moving up one capacity class can also change the battery system, chassis dimensions and turning radius. Use the model that fits the real application rather than selecting extra tonnage without checking warehouse geometry.
2,000 kg class with 48 V / 600 Ah baseline and optional lithium configuration.
View FB20 →2,500 kg at 500 mm with 1,180 mm overall width on the current specification.
View FB25 →Four Questions Before Choosing the Capacity
-
1.5 Ton Electric Forklift• 1,500 kg rated load capacity• 500 mm standard load center• 3,000 mm standard lift height• 48 V / 500 Ah battery system• Approx. 2,000 mm turning radius• 1,140 mm overall truck width• 6 kW tractionAdd to Inquiry -
2 Ton Electric Forklift• 2,000 kg rated lifting capacity• 500 mm standard load center• 3,000 mm standard lift height• 48 V / 600 Ah standard battery system• Optional 80 V / 272 Ah lithium battery• 2,120 mm outside turningAdd to Inquiry -
2.5 Ton Electric Forklift• 2,500 kg rated lifting capacity• 500 mm standard load center• 3,000 mm standard lift height• 1,180 mm compact overall width• 2,120 mm outside turning radius• 48 V / 600 Ah standard battery•Add to Inquiry -
3 Ton Electric Forklift• 3,000 kg rated lifting capacity• 500 mm standard load center• 3,000 mm standard lifting height• 80 V / 500 Ah battery system• Optional 80 V / 450 Ah lithium battery• 13 kW AC traction motor• 2,320Add to Inquiry -
3.5 Ton Electric Forklift3,500 kg rated load capacity500 mm standard load center3,000 mm standard lifting height80V electric drive system13 kW AC traction motor14 kW hydraulic pump motor2,320 mm turning radius13 / 14 km/hAdd to Inquiry -
2 Ton Electric Forklift TruckRated Load Capacity:** **2,000 kg** at 500 mm load centerStandard Lift Height:** **3,000 mm** up to 6,000 mm maximumBattery Configuration:** **CATL 80V / 271Ah** integrated LiFePO4Drive MotorsAdd to Inquiry -
2.5 Ton Electric Forklift Truck• 2,500 kg rated load capacity• 500 mm standard load center• AC electric drive for warehouse handling• 3,000 mm standard lifting height• 80 V / 272 Ah lithium option available• 1,180 mm compactAdd to Inquiry -
3 Ton Electric Forklift TruckRated Load Capacity:** **3,000 kg** at 500 mm load centerChassis IP Rating:** **IPX5 certified** high-pressure washdown safeFork Carriage Material:** Heavy-duty **Stainless Steel (SUS304)**BatteryAdd to Inquiry -
3.5 Ton Electric Forklift Truck• 3,500 kg rated load capacity• 500 mm standard load center• 3,000 mm standard lifting height• 80 V / 500 Ah battery system• Optional 80 V / 450 Ah lithium battery• 13 kW AC traction motor• 2,320 mmAdd to Inquiry
FB15–FB35 Compact Electric Forklift Selection Matrix
Battery voltage and turning radius are not the same across every capacity class. Use the selected model specification rather than one generic compact-electric value.
| Model | Rated Capacity | Load Center | Battery Reference | Turning Radius |
|---|---|---|---|---|
| FB15 | 1,500 kg | 500 mm | 48 V / 500 Ah | Approx. 2,000 mm |
| FB20 | 2,000 kg | 500 mm | 48 V / 600 Ah baseline; optional 80 V / 272 Ah lithium |
2,120 mm |
| FB25 | 2,500 kg | 500 mm | 48 V / 600 Ah baseline; optional 80 V / 272 Ah lithium |
2,120 mm |
| FB30 | 3,000 kg | 500 mm | 80 V / 500 Ah; optional 80 V / 450 Ah lithium |
2,320 mm |
| FB35 | 3,500 kg | 500 mm | 80 V electric system; optional lithium configuration |
2,320 mm |
Do Not Apply One Lithium Specification to the Whole Range
The compact electric family includes different battery architectures. FB15 uses a published 48 V / 500 Ah system, FB20 and FB25 use 48 V / 600 Ah baseline systems with lithium options, while FB30 moves to an 80 V platform.
This means battery chemistry, capacity and charger selection should be confirmed after the truck capacity and operating cycle are known.
- Working hours per shift
- Number of shifts per day
- Available charging windows
- Travel distance and lift frequency
- Lead-acid or lithium preference
- Site electrical supply
Charging Time Is Configuration-Specific
A lithium option on one model does not prove the same voltage, Ah rating, charger power or charging time for another model.
We confirm the truck, battery and charger as one operating package in the quotation.
Capacity Increases Can Change the Turning Envelope
Turning radius alone is not a working-aisle dimension. Pallet depth, fork orientation, chassis length, clearance and aisle-entry geometry should also be checked.
Choose the Capacity Class Around the Real Load Moment
1.5–2.0 Ton
Compare these classes for lighter pallet handling where compact truck dimensions are especially valuable.
2.5–3.5 Ton
Move into the higher compact classes when routine loads require additional rated capacity and the warehouse route supports the larger chassis.
Above 3.5 Ton
Compare the 4–7 ton heavy-duty electric range instead of forcing a compact truck beyond its rated application.
Typical Uses for Compact Electric Counterbalance Forklifts
Warehouse Pallet Movement
Receiving, storage transfer, staging and dispatch on suitable indoor routes.
Production Supply
Move components, raw materials and finished products between storage and production.
Indoor-Outdoor Transfer
Evaluate floor condition, gradients and weather exposure before using a warehouse electric truck on mixed routes.
Compact Counterbalance Is Not the Best Layout for Every Warehouse
Very Narrow Rack Aisles
Compare an articulated VNA truck where storage density and aisle reduction are the primary objectives.
Explore VNA Forklifts →High-Rack Storage
Compare an electric reach truck when rack access and residual capacity at height are the main selection factors.
Explore Reach Trucks →Low-Level Pallet Flow
Pallet stackers can be a more focused option for lower-capacity vertical pallet handling.
Explore Pallet Stackers →Send These Details for an FB15–FB35 Recommendation
Load
Maximum weight, dimensions and load center.
Lift
Required fork height, mast clearance and attachment.
Warehouse
Aisle, doorway, cross aisle, surface and ramp conditions.
Duty Cycle
Shift hours, charging window, quantity and destination.
Continue Your Electric Forklift Selection
1.5–3.5 Ton Electric Forklift Buying Questions
Start with maximum routine load, dimensions and actual load center. Then verify lift height, attachment and warehouse geometry before choosing FB15, FB20, FB25, FB30 or FB35.
No. Current core models use different systems. FB15 publishes 48 V / 500 Ah, FB20 and FB25 publish 48 V / 600 Ah baseline systems, while FB30 uses an 80 V system.
Lithium configurations are listed on several current models, but voltage, capacity and charger specifications are model-specific. Confirm the battery package with the selected truck.
No. Working aisle width also depends on pallet dimensions, fork-entry direction, truck length, clearance and aisle-entry geometry. Send the warehouse dimensions for a route check.
Compare a reach truck when high-rack storage and rack access are the primary tasks. For very narrow aisles, also compare articulated VNA forklifts.
Send maximum load weight and dimensions, load center, lift height, aisle and doorway dimensions, ramp conditions, shift hours, charging windows, battery preference, attachments, quantity and destination.
Send the Load and Warehouse Data Before Choosing FB15–FB35
The closest capacity number is not always the best truck. We use the load, aisle, mast and battery duty data together to narrow the appropriate compact electric forklift configuration.
- Maximum load weight and dimensions
- Required lift height
- Aisle and doorway dimensions
- Ramp and floor conditions
- Shift hours and charging windows
- Battery preference and attachments
Request an FB15–FB35 Recommendation
Please include your maximum load, pallet dimensions, required lift height, aisle width, doorway clearance, working hours, battery preference, quantity and destination.
