Technical Specifications
|
Parameter |
Specification |
|
Model |
FD360 |
|
Rated Load Capacity |
36,000 kg |
|
Load Center |
1250 mm |
|
Engine Options |
WeiChai WP10G240E341 (178 kW) / Dongfeng Cummins QSC8.3-C260 (194 kW) |
|
Transmission |
2 forward / 1 reverse gears |
|
Lifting Speed |
260 mm/s (loaded) / 280 mm/s (unloaded) |
|
Travel Speed |
25 km/h (loaded) / 28 km/h (unloaded) |
|
Ground Clearance |
400 mm (mast) / 460 mm (wheelbase center) |
|
Tire Configuration |
Front: 16.00-25 / Rear: 16.00-25 (pneumatic, 28PR) |
|
Overall Dimensions |
Length: 9760 mm / Width: 3360 mm / Height: 3460 mm (cab) |
|
Fork Dimensions |
2400×320×120 mm (standard) |
|
Item |
Project Description |
Units |
Technical Parameters |
|
FD360 |
|||
|
Features |
Rated Load |
Kg |
36000 |
|
Load Center |
mm |
1250 |
|
|
Wheelbase |
mm |
4800 |
|
|
Weight |
Operate Weight |
kg |
42200 |
|
Chassis |
Tire Specs:Front |
|
16.00-25 |
|
Tire Specs:Rear |
16.00-25 |
||
|
Tires Qty,front/rear(X-dreve wheels) |
4/2 |
||
|
Wheel tread:Front |
mm |
2430 |
|
|
Wheel tread:Rear |
mm |
2230 |
|
|
Dimensions |
Mast/carriage tilt angle(front/rear) |
Degree(°) |
6/12 |
|
Mast height(fork lowering) |
mm |
4150 |
|
|
Mast lifting height |
mm |
4000 |
|
|
Max.height |
mm |
6120 |
|
|
Height to head guard(height to cab) |
mm |
3460 |
|
|
Overall height(with forks) |
mm |
9760 |
|
|
Fork front vertical surface to the rear end of the vehicle |
mm |
7360 |
|
|
Overall width |
mm |
3360 |
|
|
Fork dimension |
mm |
2400*320*120 |
|
|
Fork carriage width |
mm |
3000 |
|
|
Mast min ground(with load) |
mm |
400 |
|
|
Wheelbase center min ground(with load) |
mm |
460 |
|
|
Min.turning Radius |
mm |
6900 |
|
|
Travel speed(with load/without load) |
km/h |
25/28 |
|
|
Performance |
Max.lifting speed(with load/without load) |
mm/s |
260/280 |
|
Tractionn |
KN |
200 |
|
|
Gradeability(with load/without load) |
% |
20/20 |
|
|
Driving brake |
Hydraulic clamp disc |
||
|
Engine |
Engine brand/model |
Optional 1 |
WeiChai Engine |
|
emission II |
WP10G240E341 9.72 6L178kW 2200r/min |
||
|
emission II |
Dongfeng cummins 6CTA8.3-C260 8.3L 194kW 2200r/min |
||
|
emission III |
Dongfeng cummins QSC8.3-C260 8.3L 194kW 2200r/min |
||
|
Rated Output |
178(Kw) |
||
|
Cylinder No |
6 |
||
|
Others |
Transmission gears(Front/rear) |
2/1 |
