Product parameters
|
General |
1 |
Model |
|
FY50 |
||
|
2 |
Power Type |
Gasoline & LPG |
||||
|
3 |
Rated Capacity |
kg |
5000 |
|||
|
4 |
Load Centre |
mm |
600 |
|||
|
Characteristic&Dimension |
5 |
Lift Height |
mm |
3000 |
||
|
6 |
Fork Size |
L×W×T |
mm |
1220×150×60 |
||
|
7 |
Mast Tilt Angle |
F/R |
Deg |
6°/12° |
||
|
8 |
Fork Overhang (Wheel center to fork face) |
mm |
590 |
|||
|
9 |
Ground Clearance(Bottom of mast) |
mm |
200 |
|||
|
10 |
Overall Dimension |
Length to face of fork(Without fork) |
mm |
3440 |
||
|
11 |
Overall Width |
mm |
2010 |
|||
|
12 |
Mast Lowered Height |
mm |
2500 |
|||
|
13 |
Mast Extended Height(With backrest) |
mm |
4415 |
|||
|
14 |
Overhead Guard Height |
mm |
2430 |
|||
|
15 |
Turning Radius (outside) |
mm |
3250 |
|||
|
Performance |
16 |
Speed |
Travel (Full load) |
km/h |
30 |
|
|
17 |
Lifting (Full load) |
mm/s |
500 |
|||
|
18 |
Max.Gradeability |
% |
20 |
|||
|
Chassis |
19 |
Tyre |
Front |
mm |
8.25-15-14PR |
|
|
20 |
Rear |
mm |
8.25-15-14PR |
|||
|
21 |
Wheelbase |
mm |
2250 |
|||
|
22 |
Self weight |
kg |
8150 |
|||
|
Power&Transmission |
23 |
Battery |
Voltage/Capacity |
V/Ah |
12/120 |
|
|
24 |
Engine |
Model |
PSI4.3L |
|||
|
25 |
Manufacture |
PSI |
||||
|
26 |
Rated output/r.p.m. |
kw |
76/2300 |
|||
|
27 |
Rated torque/r.p.m. |
N·m |
324/1700 |
|||
|
28 |
No.of Cylinder |
6 |
||||
|
29 |
Bore×Stroke |
mm |
101.6×88.4 |
|||
|
30 |
Displacement |
cc |
4300 |
|||
|
31 |
Fuel Tank Capacity |
L |
125 |
|||
|
32 |
Transmission |
Type |
Hydraulic |
|||
|
33 |
Stage |
FWD/RVS |
2/2 |
|||
