Product Parameters
|
Model |
FG35 |
|
|
Power |
Gasoline & LPG |
|
|
Rated lifting weight |
KG |
3500 |
|
Load center distance |
mm |
500 |
|
Tire size (front) |
28x9-15 |
|
|
Tire size (rear) |
6.50-10 |
|
|
Length without fork |
mm |
2800 |
|
Width |
1220 |
|
|
Overhead guard height |
2122 |
|
|
Wheelbase |
1800 |
|
|
Front/rear of overhang |
485/515 |
|
|
Front/rear wheelbase |
1210/1240 |
|
|
Minimum ground clearance |
150 |
|
|
Standard lifting height without load |
3000 |
|
|
Adjustment range of fork |
1060/250 |
|
|
Minimum turning radius (outside) |
2470 |
|
|
Mast tilt (F/R) |
(°) |
6/12° |
|
Fork length |
1070 |
|
|
Maximum hoisting speed unload/full load |
mm/s |
500/450 |
|
Maximum operating speed unload/full load |
Km/h |
19.5/18 |
|
Gradeability |
% |
<20 |
|
Maximum traction (full load/unload) |
KN |
21/16 |
|
Operating weight |
Kg |
4605 |
|
Engine brand |
GCT Nissan |
|
|
Engine model |
K25 |
|
|
Cylinder number |
4 |
|
|
Displacement |
L |
2.49 |
|
Rated power/speed |
Kw/rpm |
37.4/2300 |
|
Rated torque/speed |
Nm/rpm |
176.5/1600 |
|
Gearbox gearshift number (F/R) |
1-1 power shift |
