Precision Hydraulics
Closed Hydrostatic System: Energy - efficient operation with load - sensing technology.
Dual Hydraulic Pumps: Separate circuits for driving and lifting ensure smooth simultaneous operations.
Operator Comfort & Safety
Air - Conditioned Cab: Spacious design with panoramic glass, Bluetooth connectivity, and ergonomic controls.
Load Limiter: Real - time monitoring prevents overloading, with visual and audible alerts.
Anti - Roll Over System: Automatic shutdown if tilt exceeds 15°.
Extreme Environment Adaptation
High - Altitude Filter: Ensures engine performance in elevated work sites.
Waterproof Hydraulic Covers: Protects components in wet or dusty environments.
Key Features & Attachments
The 7018 Telescopic Handler supports a wide range of quick - change attachments tailored to specific industry needs:
Hydraulic Bucket (3.0m³)
Function: Ideal for bulk material handling of grains, soil, and aggregates.
Technology: Self - leveling mechanism ensures stability during lifting and transportation.
Applications:
Agriculture: Loading/unloading silos and distributing livestock feed.
Construction: Earthmoving in quarries and site preparation.
Video Description
Technical Specifications
|
Parameter |
Value |
|
Rated Load |
7,000 kg |
|
Max Lifting Height |
17.9 m |
|
Max Horizontal Reach |
14.4 m |
|
Engine |
Cummins QSB4.5 (119 kW) |
|
Transmission |
Hydrostatic |
|
Max Speed |
25 km/h |
|
Tire Size |
14.00 - 24 Off - Road |
|
Weight |
17,000 kg |
|
Hydraulic Oil Tank |
220 L |
|
Diesel Tank |
215 L |
Performance Advantages
|
Name of performance project |
HZTH7017 |
|
|
Outline dimension |
Length (mm) |
6720 |
|
Width (mm) |
2500 |
|
|
Height (mm) |
2710 |
|
|
Dead weight (kg) |
17000 |
|
|
Hydraulic system pressure (MPa) |
28 |
|
|
Hydraulic system flow (l/min) |
145 |
|
|
Engine |
Model |
QSB4.5-C160-30 |
|
Power (kw@rev) |
119/2200 |
|
|
Torque (N@rev) |
480/2200 |
|
|
Maximum mobile speed (km/h) |
25 |
|
|
Gradeability (º) |
30% |
|
|
Departure angle (º) |
28 |
|
|
Swing angle of rear axle frame (º) |
8 |
|
|
Tire specification |
14.00-24-28PR |
|
|
Hydraulic oil tank |
220 L |
|
|
Diesel oil tank |
215 L |
|
|
Hydraulic pump type |
Gear Pump for power steering and movements |
|
|
Boom lifting Speed |
15.1 s |
|
|
Boom Extension Speed |
10.4 s |
|
