Key Features & Attachments of 5ton 7m new telescopic forklift
The 5 Ton Telescopic Handler supports a range of quick-change attachments for tailored performance:
Hydraulic Bucket (2.0m³): Perfect for agricultural tasks like loading grain, soil, or manure. Its self-leveling function ensures precise material handling in farms and feedlots.
Forks: Designed for warehouse and logistics operations, these attachments safely stack pallets, steel beams, or construction materials with a 5-ton capacity.
Rotating Work Platform (ISO Certified): Transform the machine into a mobile aerial work platform for maintenance, inspections, or installations at heights up to 7 meters.
Hydraulic Clamp: Specifically engineered for the Stone processing industry, this tool securely grips and transports heavy stone slabs, marble, or concrete blocks.
Snow Plow/Brush: Ideal for winter maintenance, these attachments clear snow and debris from roads, parking lots, or industrial sites.
Typical Applications:
- Agriculture: Efficiently manage silo loading, hay bale handling, and livestock feed distribution.
- Construction: Transport materials to elevated sites or assist in steel erection and roofing projects.
- Logistics: Streamline container stuffing/unstuffing in ports and distribution centers.
Technical Specifications of 5 Ton 7m Height Telescopic Handlers Forklift
|
Parameter |
Value |
|
Rated Load |
5,000 kg |
|
Max Lifting Height |
7.2 m |
|
Max Horizontal Reach |
3.93 m |
|
Engine |
Cummins QSB3.9-C110-30 |
|
Power |
81 kW @ 2,200 RPM |
|
Transmission |
Hydrostatic |
|
Max Speed |
25 km/h |
|
Tire Size |
16.70-24 Off-Road |
|
Weight |
8,150 kg |
|
Name of performance project |
5 ton 7 m telehandler's parameters |
Remarks |
||
|
Outline dimension |
Length (mm) |
5150 |
Remove the pallet fork |
|
|
Width (mm) |
2250 |
|||
|
Height (mm) |
2300 |
|||
|
Dead weight (kg) |
8150 |
|||
|
Hydraulic system pressure (MPa) |
26 |
|||
|
Hydraulic system flow (l/min) |
145 |
|||
|
Hydraulic fuel tank capacity (l) |
150 |
|||
|
Engine |
Model |
QSB3.9-C110-30 |
National Standard III |
|
|
Power (kw@rev) |
81/2200 |
|||
|
Torque (N@rev) |
480/1600 |
|||
|
Maximum mobile speed (km/h) |
25 |
|||
|
Gradeability (º) |
30% |
|||
|
Departure angle (º) |
33 |
|||
|
Swing angle of rear axle frame (º) |
5 |
|||
|
Tire specification |
16.70-24 |
|||
Performance Advantages Of 5 Ton Telescopic Forklift
Superior Maneuverability:
Four-Wheel Steering & Crab Mode: Enables tight turns in confined spaces, with a minimum turning radius of 4 meters.
Swing Rear Axle: ±5° articulation ensures stability on uneven terrain.
Advanced Hydraulics:
Closed Hydrostatic System: Delivers smooth, energy-efficient operation with load-sensing technology.
Hydraulic Wet Axles: Provide durable, maintenance-free performance in harsh conditions.
Operator Comfort:
Air-Conditioned Cab: Spacious design with panoramic visibility, Bluetooth connectivity, and adjustable seating.
Ergonomic Controls: Joystick operation and intuitive dashboard reduce operator fatigue.
Video Description
Why Choose XINGHAO 5 Ton Telescopic Handler?
- Cost-Effective: Competitive 5 Ton Telehandler Price combined with low fuel consumption and long service life.
- Factory-Direct Quality: As a leading 5 Ton Telehandler Factory, we ensure strict quality control and customizable solutions.
- Global Support: Reliable after-sales service and a wide network of 5 Ton Telehandler Suppliers worldwide.
Applications Across Industries
- Agriculture: Efficiently handle grain, fertilizers, and livestock feed in farms and agricultural cooperatives.
- Warehousing: Optimize pallet handling and container operations with quick fork-to-bucket conversions.
- Construction: Transport materials to elevated work sites or support roofing and masonry tasks.
- Mining: Safely maneuver in narrow mine shafts or load/unload heavy equipment.
