Key Features & Attachments
With 10,000 lbs. of maximum lift capacity and a maximum lift height of 55 feet, the 10K telehandler is ideal for material placement at rough terrain construction and industrial sites. The 10,000 pound models include front stabilizers for additional stability and increased lift capacity.
Video Description
Technical Specifications
|
Parameter |
Value |
|
Rated Load |
5,000 kg |
|
Max Lifting Height |
10 m |
|
Max Horizontal Reach |
5.5 m |
|
Engine |
Cummins QSB3.9 - C125 - 30 |
|
Power |
81 kW @ 2,200 RPM |
|
Transmission |
Hydrostatic |
|
Max Speed |
40 km/h |
|
Tire Size |
16.70 - 24 Off - Road |
|
Weight |
9,500 kg |
|
Hydraulic Oil Tank |
145 L |
|
Diesel Tank |
160 L |
Performance Advantages
|
Name of performance project |
Performance or parameters |
Remarks |
|||
|
Outline dimension |
Length (mm) |
6040 |
Remove the pallet fork |
||
|
Width (mm) |
2320 |
||||
|
Height (mm) |
2490 |
|
|||
|
Dead weight (kg) |
9500 |
||||
|
Hydraulic system pressure (MPa) |
28 |
||||
|
Hydraulic system flow (l/min) |
110 |
||||
|
Hydraulic fuel tank capacity (l) |
145 |
||||
|
Engine |
Model |
QSB3.9-C125-30 |
National Standard III |
||
|
Power (kw@rev) |
81/2200 |
||||
|
Torque (N@rev) |
480/1600 |
||||
|
Maximum mobile speed (km/h) |
40 |
||||
|
Gradeability (º) |
35% |
||||
|
Departure angle (º) |
33 |
||||
|
Swing angle of rear axle frame (º) |
5 |
||||
|
Tire specification |
16.70-24 |
||||
|
Lifting height (mm) |
9500 |
||||
|
Max. extention |
5500 |
||||
